Using Kubeval

Kubeval is used to validate one or more Kubernetes configuration files, and is often used locally as part of a development workflow as well as in CI pipelines.

At the most basic level, Kubeval is used like so:

$ kubeval my-invalid-rc.yaml
WANR - my-invalid-rc.yaml contains an invalid ReplicationController - spec.replicas: Invalid type. Expected: integer, given: string
$ echo $?
1

Strict schemas

The Kubernetes API allows for specifying properties on objects that are not part of the schemas. However, kubectl will throw an error if you use it with such files. Kubeval can be used to simulate this behaviour using the --strict flag.

$ kubeval additional-properties.yaml
PASS - additional-properties.yaml contains a valid ReplicationController
$ echo $?
0
$ kubeval --strict additional-properties.yaml
WARN - additional-properties.yaml contains an invalid ReplicationController - spec: Additional property replicas is not allowed
$ echo $?
1

If you're using kubectl you may find it useful to always set the --strict flag.

Stdin

Alternatively Kubeval can also take input via stdin which can make using it as part of an automated pipeline easier by removing the need to securely manage temporary files.

$ cat my-invalid-rc.yaml | kubeval
WARN -  stdin contains an invalid ReplicationController - spec.replicas: Invalid type. Expected: integer, given: string
$ echo $?
1

To make the output of pipelines more readable, a filename can be injected to replace stdin in the output:

$ cat my-invalid-rc.yaml | kubeval --filename="my-invalid-rc.yaml"
WARN -  my-invalid-rc.yaml contains an invalid ReplicationController - spec.replicas: Invalid type. Expected: integer, given: string
$ echo $?
1

CRDs

Currently kubeval relies on schemas generated from the Kubernetes API. This means it's not possible to validate resources using CRDs. Currently you need to pass a flag to ignore missing schemas, though this may change in a future major version.

$ kubeval --ignore-missing-schemas fixtures/test_crd.yaml
WARN - Set to ignore missing schemas
WARN - fixtures/test_crd.yaml containing a SealedSecret was not validated against a schema

If you would prefer to be more explicit about which custom resources to skip you can instead provide a list of resources to skip like so.

$ kubeval --skip-kinds SealedSecret fixtures/test_crd.yam
WARN - fixtures/test_crd.yaml containing a SealedSecret was not validated against a schema

Helm

Helm chart configurations generally have a reference to the source template in a comment like so:

# Source: chart/templates/frontend.yam

When kubeval detects these comments it will report the relevant chart template files in the output.

$ kubeval fixtures/multi_valid_source.yaml
PASS - chart/templates/primary.yaml contains a valid Service
PASS - chart/templates/primary.yaml contains a valid ReplicationControlle

Configuring Output

The output of kubeval can be configured using the --output flag (-o).

As of today kubeval supports the following output types:

  • Plaintext --output=stdout
  • JSON: --output=json
  • TAP: --output=tap

Example Output

Plaintext

$ kubeval my-invalid-rc.yaml
WARN - my-invalid-rc.yaml contains an invalid ReplicationController - spec.replicas: Invalid type. Expected: integer, given: string

JSON

$ kubeval fixtures/invalid.yaml -o json
[
     {
             "filename": "fixtures/invalid.yaml",
             "kind": "ReplicationController",
             "status": "invalid",
             "errors": [
                     "spec.replicas: Invalid type. Expected: [integer,null], given: string"
             ]
     }
]

TAP

 $ kubeval fixtures/invalid.yaml -o tap
1..1
not ok 1 - fixtures/invalid.yaml (ReplicationController) - spec.replicas: Invalid type. Expected: [integer,null], given: string

Full usage instructions

$ kubeval --help
Validate a Kubernetes YAML file against the relevant schema

Usage:
  kubeval <file> [file...] [flags]

Flags:
  -d, --directories strings         A comma-separated list of directories to recursively search for YAML documents
      --exit-on-error               Immediately stop execution when the first error is encountered
  -f, --filename string             filename to be displayed when testing manifests read from stdin (default "stdin")
      --force-color                 Force colored output even if stdout is not a TTY
  -h, --help                        help for kubeval
      --ignore-missing-schemas      Skip validation for resource definitions without a schema
  -v, --kubernetes-version string   Version of Kubernetes to validate against (default "master")
      --openshift                   Use OpenShift schemas instead of upstream Kubernetes
  -o, --output string               The format of the output of this script. Options are: [stdout json]
      --schema-location string      Base URL used to download schemas. Can also be specified with the environment variable KUBEVAL_SCHEMA_LOCATION
      --skip-kinds strings          Comma-separated list of case-sensitive kinds to skip when validating against schemas
      --strict                      Disallow additional properties not in schema
      --version                     version for kubeval

The command has three important features:

  • You can pass one or more files as arguments, including using wildcard expansion. Each file will be validated in turn, and kubeval will exit with a non-zero code if any of the files fail validation.
  • You can toggle between the upstream Kubernetes definitions and the expanded OpenShift ones using the --openshift flag. The default is to use the upstream Kubernetes definitions.
  • You can pass a version of Kubernetes or OpenShift and the relevant type schemas for that version will be used. For instance:
$ kubeval -v 1.6.6 my-deployment.yaml
$ kubeval --openshift -v 1.5.1 my-deployment.yaml
